Space
Space is a unique and extreme operating environment. Vacuum, cosmic and thermal radiation, cost implications for launch thrust, vibration, high cost of failure and repair make it a specialist field with exacting requirements.
Harwin for Space
Harwin interconnects are used in build programmes by some of the world’s leading space projects.
- Many years experience supplying the space industry
- Lightweight, small footprint, high reliability interconnects
- Certified to EN9100D / AS9100D
Featured projects
- Project: Base satellite communications system
- Challenge: With many cables and a long Bill of Materials (BOM) the customer wanted to stick with a consistent connection type for the different cable-to-board connections, on top of a rugged connector system for an outdoor operating environment.
- Solution: Datamate J-Tek 2-row and 3-row connectors use the same cabling and connection system across a wide range of connector sizes – all capable of meeting the customer’s environmental concerns.
- Project: Satellite TV from Geostationary Orbit.
- Challenge: panel-to-panel connection rugged enough to survive launch and orbiting conditions for enclosed server units to launch and operate in earth-orbit satellites, yet easy to blind-mate on assembly.
- Solution: Using Datamate J-Tek with a combination of female guide pins and male panel mount, both cable connections provide panel mounting with space-grade, high-reliability performance.
Connectors & Hardware for Space Applications
Specify Harwin for high reliability in ground applications as well as the unique and extreme environment of space itself.
Gecko-SL, Gecko-MT, Gecko Latch Connectors
- 2A signal, 10A power
- Outgassing levels meet NASA / ESA requirements
- -65°C to +150°C; 20g Vibration, 100g Shock
- Components to full cable assemblies available
Datamate J-Tek, Mix-Tek, Power, Coax, L-Tek Connectors
- 3A signal, up to 40A power, 50Ω coax
- Outgassing levels meet NASA / ESA requirements
- -55°C to +125°C; 10g Vibration, 100g Shock
- Components to full cable assemblies available
M300 Connectors
- Up to 10A power
- Outgassing levels meet NASA / ESA requirements
- -65°C to +175°C; 20g Vibration, 100g Shock
- Components to full cable assemblies available
EMC Shielding
- SMT Clips and removable Nickel Silver Cans
- Clips available in corner and very low profile
- 0.15/0.2/0.3mm thick cans ideal for high frequency
- Easy for rework and maintenance
PCB Sockets
- 2A to 20A options; 2, 3, 4 and 6 beam contacts
- Mating pin sizes Ø0.46mm to Ø2.30mm
- SMT and throughboard variations
- Hi-Rel contact design on two-piece sockets
