Metering & Measurement

Whether in stable, air-conditioned environments, or harsh terrain exposed to the elements, quality is a necessity where monitoring and metering products must not fail to avoid issues with data collection and ongoing operations.

Reliable Metering & Measurement

Specify Harwin for high reliability and durability in must-not-fail monitoring and metering applications.

  • Many years experience supplying parts for monitoring & metering
  • Lightweight, reliable & cost-effective interconnects
  • Certified to EN9100D / AS9100D

Featured Projects

  • Project: Location and temperature reporting from servo motors
  • Challenge: With a small footprint, it must be robust enough to withstand demanding environments. Shorter terminations required for Pin-In-Hole reflow (PIHR) solder processes with tape and reel packaging.
  • Solution: Datamate L-Tek connectors with 2mm terminations, suitable for PIHR processing, packaged in tape-and-reel. The Datamate L-Tek range is compact, robust, and proven in challenging applications.
  • Project: Gas Meter for in-home metering
  • Challenge: Built for the Dutch market, shielding components were required for in-home gas supply metering units with strict RF attenuation profile requirements in a low profile, space constrained area.
  • Solution: Micro shield clips and low profile cans to minimise space requirement and protect components from damage in harsh and extreme environments.

Connectors & Hardware for Metering and Measurement

Specify Harwin for uninterrupted data flows even in the harshest operating environments.

Archer Kontrol Connectors

  • 1.2A  per contact
  • Polarized and shrouded; ready-made cables
  • Board-to-board variable height from 8-20mm
  • 3Gbits/s data rate

Learn more about Archer Kontrol

Archer, M20, M22, M30, M40 PCB Connectors

  • 1mm to 2.54mm pitch
  • 0.5A to 3A per contact (pitch dependent)
  • Board-to-board and board-to-cable variations
  • Cost-effective solutions stocked in depth

Learn more about PCB connectors

Spring Contacts & Pads, Pogo Pins

  • Free heights from 1.23mm to 8.20mm
  • High mating durability – 1K to 10K min cycles
  • Working heights from 0.90mm to 7.10mm
  • 1A to 9A max (design dependent)

Learn more about SMT contacts, pads & pogo pins

EMC Shielding

  • SMT Clips and removable Nickel Silver Cans
  • Clips available in corner and very low profile
  • 0.15/0.2/0.3mm thick cans ideal for high frequency
  • Easy for rework and maintenance

Learn more about EMC shielding

PCB Sockets

  • 2A to 20A options; 2, 3, 4 and 6 beam contacts
  • Mating pin sizes Ø0.46mm to Ø2.30mm
  • SMT and throughboard variations
  • Hi-Rel contact design on two-piece sockets

Learn more about PCB Sockets

PCB Hardware

  • SMT test points & cable management clips
  • Fixed & removable jumper links
  • Coin cell holders
  • Terminals & spacers / pillars / standoffs

Learn more about PCB Hardware

Explore our product range

Durable Industrial Connectors View all
PCB Connectors View all
EMC Shielding View all
Spring Contacts View all
PCB Hardware View all
Throughboard PCB Sockets View all
