M80C151056C
8+8 Pos. Female DIL Cable Assembly, 70mm, double-end, Latches
2.00mm Pitch High-Reliability Connector - Datamate L-Tek
Loading… Check availability
3 similar products View products
Traceparts account required
Product Description
- Double Row Female cable assembly; 16 (8+8) contacts on first end, two 8 (4+4) contacts on second end, 70mm long. Multi-color cable insulation, 24 and 28 AWG wire sizes.
- Manufactured with the 16-contact M80-8881605 and the 8-contact M80-8880805 crimp connectors. Gold finish on contact areas.
- For complete pin numbering or pin out information, see Component Specification C005XX.
Traceparts account required
Technical Details
Specification
EU RoHS Status:
Contact Pitch:
2.00mm (0.079")
Contact Gender:
Female/Socket/Jack
Connector Orientation:
Straight
Connection Type:
Cable Assembly
Cable Conductor Size:
24 AWG & 28 AWG
Mating Pin Size:
Ø0.5mm
Current Rating:
3.3A max individual contact, 3A max simultaneous (25°C)
Operating Temperature:
-55°C to +125°C
Style of Latches:
Compatible with latches
Polarising Features:
Yes
End Stackable:
No
Side Stackable:
No
Can be cut to another size:
No
Number of Rows:
2
Number of Signal Contacts:
16
Materials
Finish / Plating on Termination:
Gold
Finish / Plating on Contact Surface:
Gold
Base Material of Contact:
Beryllium Copper contact clip, Brass shell
Housing Material:
PBT
Housing Colour:
Black
Housing Material UL Rating:
UL94V-0
Packaging Style:
Bulk/Loose
Dimensions
Overall Dimensions (L x W x D) in mm:
See Technical Drawing
Mating Profiles:
