M30-6000646

6 Pos. Male SIL Vertical SMT Conn.

1.25mm (0.049") Pitch PCB Connector - M30 Cable-To-Board

  • Single Row Male Vertical connector, Surface Mount with Tin finish – 6 contacts.
  • Surface Mount hold-down tabs, and windows for bump latches on mating connector.
  • Packaged in tubes.
Add to Favorites

Technical Details

Specification

Contact Pitch:

1.25mm (0.049")

Contact Gender:

Male/Plug

Connector Orientation:

Vertical

Connection Type:

Surface Mount (SMT)

Mating Pin Size:

0.35mm square

Current Rating:

1A per contact

Operating Temperature:

-25°C to +85°C

Soldering Data:

Max Solder Temperature: 260°C for 10 seconds

Polarising Features:

Yes

End Stackable:

No

Side Stackable:

No

Can be cut to another size:

No

Number of Rows:

1

Number of Signal Contacts:

6

Materials

Finish / Plating on Termination:

100% Tin over Nickel

Finish / Plating on Contact Surface:

100% Tin over Nickel

Base Material of Contact:

Brass

Housing Material:

Polyamide (Nylon) 6T/66

Housing Colour:

Natural

Housing Material UL Rating:

UL94V-0

Packaging Style:

Tube

Dimensions

Individual Part Weight:

0.207g

Overall Dimensions (L x W x D) in mm:

12.25 x 4.90 x 5.60

Height of Connector above PCB:

4.80mm

Availability

159 in stock

Info Circle

Popular products are manufactured regularly, typically in stock and are not subject to minimum quantity requirements.

Popular product
Distributor Location Quantity (Updated Daily)
Distributor Digi-Key
Location Global
Quantity (Updated Daily) 121
Distributor Farnell
Location Europe
Quantity (Updated Daily) 23
Distributor Newark
Location USA
Quantity (Updated Daily) 15
