Z80-295

Datamate Mix-Tek Power Crimp contact Positioner

HRi
HRi
HRi

Traceparts account required

Z80-295

Datamate Mix-Tek Power Crimp contact Positioner


4.00mm Pitch High-Reliability Connector - Datamate Power Tooling

  • Positioner for Datamate Mix-Tek Power Crimp contacts of - for correctly positioning crimps in tool whilst crimping.

  • Suitable for power contacts M80-328, M80-329, M80-338, M80-339.

  • Use with Hand Crimp Tool Z80-294.


Checking stock availability...

Check Availability

Further Details

Jump To:

Technical Details

Specification

Downloads

Environmental Compliance

Technical Documentation

Product Information

Technical Details

Specifications

  • Contact Pitch:

    2.00mm (0.079")

  • Packaging Style:

    Single Pack

  • RoHS Status:

    Not applicable to RoHS (2015/863/EU)

  • Weight:

    67g

  • Dimensions:

    45.00 x 45.00 x 47.00 (in box)
