Ganged 50 Ohm coax multiport Male Single-Ended cable assembly, 500mm long - 4 contacts. Fitted with internally threaded jackscrews with extended lugs for rear panel mount. Use hex socket bolt M80-2320000B or slotted bolt M80-2270000B for mounting to panels up to 3mm thickness.
Manufactured with M80-315 Coax straight cable contacts, M80-273MU04-00-00 cable housing, assembled to tan RG178 coax cable. Gold finish on contact areas.
For complete pin numbering or pin out information, see the Component Specification C005XX.
View Technical Details
In Stock
Further Details
Jump To:
Product Characteristics
Materials
Dimensions
Technical Documentation
Product Information
Test Reports
Environmental Compliance
Technical Details
Product Characteristics
End Stackable:
No
Style of Jackscrews:
Internal Thread Fixing with Rear Panel Mount
Number of Rows:
1
Connector Orientation:
Straight
Country of Origin:
GB
Side Stackable:
No
Number of Power/Coax Contacts:
4
Operating Temperature:
-55°C to +125°C
RoHS Status:
RoHS Compliant (2015/863/EU) with Exemption 6c
Current Rating:
0.5A per contact
Polarised:
Yes
Cuttable:
No
Materials
Finish / Plating on Contact Surface:
Gold
Housing Material:
PPS
Base Material of Contact:
Phosphor Bronze inner contact, Brass outer contact
Flammability Rating:
UL94V-0
Packaging Style:
Bulk/Loose
Finish / Plating on Termination:
Gold
Housing Colour:
Black
Dimensions
Contact Pitch:
4.00mm (0.157")
Weight:
19.502g
Dimensions:
500.30 x 26.00 x 5.50
Thread Size:
M2
Wire Size:
Ø2mm (RG178) coax
