Home > M80-5S21205MD
Discontinued

M80-5S21205MD

6+6 Pos. Male DIL Horizontal SMT Conn. 101Lok

2.00mm Pitch High-Reliability Connector - Datamate J-Tek

  • Discontinued – check the nearest Alternative products below.
  • Double Row, Surface Mount connector, 101Lok retainers with 5mm board mount – 12 contacts (6+6).
  • Gold finish on contact area and termination. Slotted bolts provided for assembly to board mount jackscrews. For spare board mount bolts, order M80-2270000B. For complete pin numbering or pin out information, see Component Specification C005XX.

Downloads

Technical Drawing / Datasheet - M80-5S2XXXXMD.pdf

PDF Download

Discontinuation Notification 27-Feb-2023 - Discontinued products

PDF Download
