3+3 Pos. Female DIL Cable Housing, 101Lok
2.00mm Pitch High-Reliability Connector - Datamate J-Tek
- J-Tek Female cable housing fitted with slotted head 101Lok bayonet-style fixings. Accommodates 6 (3+3) signal contacts.
- Ideal for use with M80-2060005 T-Contact (22AWG), but can also be used with other female signal crimp contacts from the Datamate range.
- For complete pin numbering or pin out information, see Component Specification C005XX.
EU RoHS Status:
Dependent on assembled contacts
-55°C to +125°C
Style of Jackscrews:
101Lok Bayonet Fixing with Slotted Head
Can be cut to another size:
Number of Rows:
Number of Signal Contacts:
Housing Material UL Rating:
Individual Part Weight:
Overall Dimensions (L x W x D) in mm:
16.00 x 5.50 x 10.90
266 in stock
Popular products are manufactured regularly, typically in stock and are not subject to minimum quantity requirements.
