2+2 Pos. Female DIL Vertical Throughboard Conn. Jackscrews
2.00mm Pitch High-Reliability Connector - Datamate J-Tek
- Double Row, 3mm PC Tail connector with Hexagonal slotted jackscrews – 4 contacts (2+2).
- Gold finish on contact clip, Tin finish on termination.
EU RoHS Status:
PC Tail / Throughboard
Mating Pin Size:
-55°C to +125°C
Max Solder Temperature: 260°C for 10 seconds
Style of Jackscrews:
Can be cut to another size:
Number of Rows:
Number of Signal Contacts:
Finish / Plating on Termination:
100% Tin over Nickel
Finish / Plating on Contact Surface:
Base Material of Contact:
Beryllium Copper contact clip, Brass shell
Housing Material UL Rating:
Individual Part Weight:
Overall Dimensions (L x W x D) in mm:
14.00 x 5.50 x 8.50
Height of Connector above PCB:
Length of Throughboard Tail:
AvailabilityLimited availability or made-to-order
*Stock available: contact distributor to purchase
M80-4000442 CAD Model (ZIP file containing STP and IGES)Download
Test Report HT004 - Datamate J-Tek Environmental - Vibration, Shock, Bump, Acceleration and other tests
