Home > M80-4000000FS-03-305-00-000
Active Product

M80-4000000FS-03-305-00-000

3 Pos. Female SIL RG178 Cable Conn. Kit, Jackscrews for Hoods

4.00mm Pitch High-Reliability Connector - Datamate Coax

Add to Favorites

Made to order

8 similiar products View products

Samacsys account required

Download

No login is required

Product Description

  • Complete kit: housing (with slotted jackscrews for hoods) with 3 x coax contacts supplied loose.
  • Coax crimp contact suitable for RG178 (Ø2mm max insulation diameter). Gold finish on contact area and termination.
  • For complete pin numbering or pin out information, see Component Specification C005XX.

Technical Details

Specification

Contact Pitch:

4.00mm (0.157")

Contact Gender:

Female/Socket/Jack

Connector Orientation:

Straight

Connection Type:

Cable (Crimp)

Cable Conductor Size:

Ø2mm (RG178)

Current Rating:

0.5A per contact

Operating Temperature:

-55°C to +125°C

Style of Jackscrews:

Long Floating Jackscrew for Hoods with Slotted Head (Standard Gender)

Polarising Features:

Yes

End Stackable:

No

Side Stackable:

No

Can be cut to another size:

No

Number of Rows:

1

Number of Special (Power or Coax) Contacts:

3

Materials

Finish / Plating on Termination:

Gold

Finish / Plating on Contact Surface:

Gold

Base Material of Contact:

Beryllium Copper inner contact, Brass outer shell

Housing Material:

PPS

Housing Colour:

Black

Housing Material UL Rating:

UL94V-0

Packaging Style:

Single Pack

Dimensions

Individual Part Weight:

2.144g

Overall Dimensions (L x W x D) in mm:

22.00 x 5.50 x 18.70

Thread Size:

M2

Frequently Asked Questions Ask a Question

No questions have been asked yet. Click here to ask a question.

Downloads

TECHNICAL DOCUMENTS

TEST REPORTS

ENVIRONMENTAL COMPLIANCE

RoHS Compliant (2015/863/EU) with Exemption 6c
