Product Characteristics

• End Stackable:

  No

• Entry Style:

  Dual Entry (Bottom Entry, Top Entry)

• Mating Pin Size:

  0.4mm square

• Number of Rows:

  1

• Connector Orientation:

  Vertical

• Country of Origin:

  TW

• Side Stackable:

  No

• Number of Signal Contacts:

  2

• Operating Temperature:

  -40°C to +105°C

• RoHS Status:

  RoHS Compliant (2015/863/EU) with no Exemption required

• Current Rating:

  1A per contact

• Soldering Data:

  Max Solder Temperature: 260°C for 10 seconds

• Polarised:

  No

• Cuttable:

  No

Materials

• Finish / Plating on Contact Surface:

  Gold

• Housing Material:

  Polyamide (Nylon) 9T

• Base Material of Contact:

  Phosphor Bronze

• Flammability Rating:

  UL94V-0

• Packaging Style:

  Tube

• Finish / Plating on Termination:

  100% Tin over Nickel

• Housing Colour:

  Black

Dimensions

• Contact Pitch:

  1.27mm (0.05")

• Weight:

  0.021g

• Dimensions:

  2.94 x 3.10 x 2.10

• Height of Connector above PCB:

  2.10mm
