Product Characteristics

• End Stackable:

  No

• Number of Rows:

  2

• Connector Orientation:

  Vertical

• Country of Origin:

  CN

• Side Stackable:

  No

• Number of Signal Contacts:

  21

• Operating Temperature:

  -20°C to +125°C

• RoHS Status:

  RoHS Compliant (2015/863/EU) with no Exemption required

• Current Rating:

  0.5A per contact

• Soldering Data:

  Max Solder Temperature: 260°C for 10 seconds

• Polarised:

  Yes

• Cuttable:

  No

Materials

• Finish / Plating on Contact Surface:

  100% Tin over Nickel

• Housing Material:

  LCP

• Base Material of Contact:

  Phosphor Bronze

• Flammability Rating:

  UL94V-0

• Packaging Style:

  Tape and Reel

• Finish / Plating on Termination:

  100% Tin over Nickel

• Housing Colour:

  Natural

Dimensions

• Contact Pitch:

  1.00mm (0.039")

• Weight:

  0.245g

• Dimensions:

  16.10 x 5.60 x 4.30

• Height of Connector above PCB:

  3.30mm
