Home > M30-1100600
Active

M30-1100600

6 Pos. Female SIL Cable Housing

1.25mm (0.049") Pitch PCB Connector - M30 Cable-To-Board

  • Single Row female crimp housing – 6 contact.
  • Bump latches for added retention to mating connector.
  • Use with crimp contacts M30-1050046, M30-1060046 or pre-crimped contacts M30-90 series.
Add to Favorites

Technical Details

Specification

Contact Pitch:

1.25mm (0.049")

Contact Gender:

Female/Socket/Jack

Connector Orientation:

Straight

Connection Type:

Cable (Crimp)

Mating Pin Size:

0.35mm square

Current Rating:

1A per contact

Operating Temperature:

-25°C to +85°C

Polarising Features:

Yes

End Stackable:

No

Side Stackable:

No

Can be cut to another size:

No

Number of Rows:

1

Number of Signal Contacts:

6

Materials

Housing Material:

Polyamide (Nylon) 66

Housing Colour:

Natural

Housing Material UL Rating:

UL94V-0

Packaging Style:

Bulk/Loose

Dimensions

Individual Part Weight:

0.056g

Overall Dimensions (L x W x D) in mm:

9.15 x 3.20 x 4.00

Availability

8,410 in stock

Info Circle

Low availability or made to order: This product is typically manufactured to order. When out of stock, minimum order quantities may apply.

Limited availability or made-to-order
Distributor Location Quantity (Updated Daily)
Distributor Iconnexion Asia Pte Ltd
Location Asia
Quantity (Updated Daily) 7000
Distributor Mouser Electronics Inc
Location Global
Quantity (Updated Daily) 550
Distributor Farnell
Location Europe
Quantity (Updated Daily) 460
Distributor Newark
Location USA
Quantity (Updated Daily) 400

Questions & Answers Ask a Question

No questions have been asked yet. Click here to ask a question.

Downloads

TECHNICAL DOCUMENTS

ENVIRONMENTAL COMPLIANCE

PDF

RoHS Compliant (2015/863/EU) with no Exemption required
