M30-1100300

3 Pos. Female SIL Cable Housing

1.25mm (0.049") Pitch PCB Connector - M30 Cable-To-Board

  • Single Row female crimp housing – 3 contact.
  • Bump latches for added retention to mating connector.
  • Use with crimp contacts M30-1050046, M30-1060046 or pre-crimped contacts M30-90 series.
Add to Favorites

Technical Details

Specification

Contact Pitch:

1.25mm (0.049")

Contact Gender:

Female/Socket/Jack

Connector Orientation:

Straight

Connection Type:

Cable (Crimp)

Mating Pin Size:

0.35mm square

Current Rating:

1A per contact

Operating Temperature:

-25°C to +85°C

Polarising Features:

Yes

End Stackable:

No

Side Stackable:

No

Can be cut to another size:

No

Number of Rows:

1

Number of Signal Contacts:

3

Materials

Housing Material:

Polyamide (Nylon) 66

Housing Colour:

Natural

Housing Material UL Rating:

UL94V-0

Packaging Style:

Bulk/Loose

Dimensions

Individual Part Weight:

0.028g

Overall Dimensions (L x W x D) in mm:

5.40 x 3.20 x 4.00

Availability

21,751 in stock

Info Circle

Low availability or made to order: This product is typically manufactured to order. When out of stock, minimum order quantities may apply.

Limited availability or made-to-order
Distributor Location Quantity (Updated Daily)
Distributor Iconnexion Asia Pte Ltd
Location Asia
Quantity (Updated Daily) 7000
Distributor TTI Europe
Location Europe
Quantity (Updated Daily) 5000
Distributor Mouser Electronics Inc
Location Global
Quantity (Updated Daily) 3251
Distributor Farnell
Location Europe
Quantity (Updated Daily) 2250
Distributor Newark
Location USA
Quantity (Updated Daily) 2250
Distributor Anglia
Location Europe
Quantity (Updated Daily) 2000

Questions & Answers Ask a Question

No questions have been asked yet. Click here to ask a question.

Downloads

TECHNICAL DOCUMENTS

PDF

Technical Drawing / Datasheet - M30-110.pdf

ZIP

M30-1100300 CAD Model (ZIP file containing STP and IGES)

Download
PDF

C025XX Component Specification - M30 Series (1.25mm pitch PCB connectors)

ENVIRONMENTAL COMPLIANCE

PDF

RoHS Compliant (2015/863/EU) with no Exemption required

PDF

REACH Harwin statement (12-Feb-2021) including 211 SVHC (19-Jan-2021), Annex XIV & XVII

XLSX

Conflict Minerals Reporting Template (CMRT 6.01) - Company Summary Statement

XLSX

Cobalt Reporting Template (CRT 2.2) - Company Summary Statement

PDF

Environmental Legislation Statement (12-Feb-2021) - includes all material legislations

PDF

Material composition for M30-110 series

INSTRUCTION SHEETS

PDF

Product Training Module - Overview of the Fine Pitch connectors, 1.25mm pitch and smaller

PDF

Product Training Module - Cable Connectors and Assemblies from Harwin

PDF

Product Training Module - Cable Products from Harwin

OTHER DOWNLOADS

PDF

Catalog page - M30 Female Cable Housing

PDF

Catalog page - M30 Connectors Specification, Mating Profiles
