6 Pos. Male SIL Vertical SMT Conn. (T+R)
2.00mm (0.079") Pitch PCB Connector - M22 Series
EU RoHS Status:
Surface Mount (SMT)
Mating Pin Size:
2A per contact
-40°C to +105°C
Max Solder Temperature: 260°C for 10 seconds
Can be cut to another size:
Number of Rows:
Number of Signal Contacts:
Finish / Plating on Termination:
Finish / Plating on Contact Surface:
Base Material of Contact:
Polyamide (Nylon) 9T
Housing Material UL Rating:
Tape and Reel
Individual Part Weight:
Overall Dimensions (L x W x D) in mm:
12.00 x 9.00 x 2.00
Height of Connector above PCB:
4,000 in stock
Low availability or made to order: This product is typically manufactured to order. When out of stock, minimum order quantities may apply.
