Double Row Surface Mount, Dual (Top and Bottom) Entry, 7.5mm connector height - 8 contacts (4+4).
Gold finish on contact area, Tin finish on termination.
Supplied on Tape and Reel with pick and place cap.
View Technical Details
Checking stock availability...
Related Products
Further Details
Jump To:
Product Characteristics
Materials
Dimensions
Technical Documentation
Product Information
Environmental Compliance
Technical Details
Product Characteristics
End Stackable:
No
Entry Style:
Dual Entry (Bottom Entry, Top Entry)
Mating Pin Size:
0.64mm square
Number of Rows:
2
Connector Orientation:
Vertical
Country of Origin:
CN
Side Stackable:
No
Number of Signal Contacts:
8
Operating Temperature:
-40°C to +105°C
RoHS Status:
RoHS Compliant (2015/863/EU) with no Exemption required
Current Rating:
3A per contact
Soldering Data:
Max Solder Temperature: 260°C for 10 seconds
Polarised:
No
Cuttable:
No
Materials
Finish / Plating on Contact Surface:
Gold
Housing Material:
Polyamide (Nylon) 6T
Base Material of Contact:
Phosphor Bronze
Flammability Rating:
UL94V-0
Packaging Style:
Tape and Reel
Finish / Plating on Termination:
100% Tin over Nickel
Housing Colour:
Black
Dimensions
Contact Pitch:
2.54mm (0.1")
Weight:
0.836g
Dimensions:
10.36 x 6.50 x 7.50
Height of Connector above PCB:
7.50mm
