Product Characteristics

• Mating Pin Size:

  Ø0.8mm

• Connector Orientation:

  Vertical

• Country of Origin:

  GB

• Number of Power/Coax Contacts:

  1

• Number of Signal Contacts:

  1

• Operating Temperature:

  -55°C to +125°C

• RoHS Status:

  RoHS Compliant (2015/863/EU) with Exemption 6c

• Current Rating:

  10A max at 25°C, 7.5A max at 85°C

• Soldering Data:

  Max Solder Temperature: 260°C for 10 seconds

Materials

• Finish / Plating on Contact Surface:

  Gold

• Base Material of Contact:

  Beryllium Copper contact clip, Brass shell

• Packaging Style:

  Bulk/Loose

• Finish / Plating on Termination:

  100% Tin over Nickel

Dimensions

• Weight:

  0.08g

• Dimensions:

  5.70 x Ø2.33

• PC Tail Length:

  4.80mm

• Height of Connector above PCB:

  0.90mm
