Sockets - Individual Throughboard PCB Socket
PC Board Socket for mating Ø0.80mm Pin, retention feature - Gold finish on contact area, Tin finish on termination.
Uses 4-finger Beryllium Copper contact clip - Vibration 10-2,000Hz, 10G, 6 hours.
Product still requires soldering for electrical connection.
View Technical Details & Downloads
Checking stock availability...
Check Availability
Related Products
Further Details
Jump To:
Product Characteristics
Materials
Dimensions
Product Information
Technical Documentation
Environmental Compliance
Technical Details
Product Characteristics
Entry Style:
Top Entry
Mating Pin Size:
Ø0.8mm
Connector Orientation:
Vertical
Country of Origin:
GB
Operating Temperature:
-55°C to +125°C
RoHS Status:
RoHS Compliant (2015/863/EU) with Exemption 6c
Current Rating:
10A max at 25°C, 7.5A max at 85°C
Soldering Data:
Max Solder Temperature: 260°C for 10 seconds
Materials
Finish / Plating on Contact Surface:
Gold
Base Material of Contact:
Beryllium Copper contact clip, Brass shell
Packaging Style:
Bulk/Loose
Finish / Plating on Termination:
100% Tin over Nickel
Dimensions
Weight:
0.082g
Dimensions:
5.70 x Ø2.33
PC Tail Length:
4.80mm
Height of Connector above PCB:
0.90mm
Downloads
Technical Drawing / Datasheet - H8501.pdf
C010XX Component Specification - PC Board Sockets for 0.80mm pins
Outgassing data for Harwin products (plastics)
RoHS - H8501-01
Material composition for H8501 series
REACH - Harwin statement including all current SVHCs & Annex XIV & XVII
Environmental Legislation Statement - includes all material legislations
Extended Mineral Reporting Template (EMRT) - Company Summary Statement
Conflict Minerals Reporting Template (CMRT) - Company Summary Statement
