G125-MC10605L0-0300F
3+3 Pos. Male-Female DIL 26AWG Cable Assembly, 300mm, no Latches
1.25mm Pitch High-Reliability Connector - Gecko with Latches
In stock Check availability
11 similar products View products
Traceparts account required
Product Description
- Male-to-Female (Female-to-Male) with white 26 AWG cable, 300mm long – 6 contacts (3+3). Male connector housing is not fitted with latches. Female connector housing is compatible for mating to male connectors with latches.
- Manufactured with G125-1010005 male crimp contacts, G125-3040696L0 male Double Row crimp housing, G125-0010005 female crimp contacts and G125-2040696L0 female Double Row crimp housing. Gold finish on contact area.
- For complete pin numbering or pin out information, see Component Specification C125XX.
Traceparts account required
Technical Details
Specification
EU RoHS Status:
Contact Pitch:
1.25mm (0.049")
Contact Gender:
Male & Female
Connector Orientation:
Straight
Connection Type:
Cable Assembly
Cable Conductor Size:
26AWG
Mating Pin Size:
Ø0.4mm
Current Rating:
2.8A max individual contact, 2A max simultaneous (25°C)
Operating Temperature:
-65°C to +150°C
Style of Latches:
None
Polarising Features:
Yes
End Stackable:
No
Side Stackable:
No
Can be cut to another size:
No
Number of Rows:
2
Number of Signal Contacts:
6
Materials
Finish / Plating on Termination:
Gold
Finish / Plating on Contact Surface:
Gold
Base Material of Contact:
Brass (Male), Beryllium Copper (Female)
Housing Material:
Polyamide (Nylon) 4T
Housing Colour:
Green
Housing Material UL Rating:
UL94V-0
Packaging Style:
Bulk/Loose
Dimensions
Individual Part Weight:
3.943g
Overall Dimensions (L x W x D) in mm:
300.00 x 6.30 x 4.90
Mating Profiles:
Frequently Asked Questions Ask a Question
What is the process or technician training certification ensured for pre-crimped and wired connectors?
Our operators assembling all our cable assemblies are trained and certified to IPC-A-620 requirements, as well as our own specific tooling instructions for the products involved.
