3+3 Pos. Female DIL 26AWG Cable Assembly, 300mm, double-end, for Latches
1.25mm Pitch High-Reliability Connector - Gecko with Latches
EU RoHS Status:
Cable Conductor Size:
Mating Pin Size:
-65°C to +150°C
Style of Latches:
Compatible with latches
Can be cut to another size:
Number of Rows:
Number of Signal Contacts:
Finish / Plating on Termination:
Finish / Plating on Contact Surface:
Base Material of Contact:
Polyamide (Nylon) 4T
Housing Material UL Rating:
Individual Part Weight:
Overall Dimensions (L x W x D) in mm:
300.00 x 6.30 x 4.90
AvailabilityLimited availability or made-to-order
*Stock available: contact distributor to purchase
Questions & Answers Ask a Question
Do you have a tool to help separate this connector when it is latched to the mating half?
The tool you need is the Z125-9260600 – this will help push in the two latch buttons when the connectors are engaged, so you can then separate the mated connectors. Consult the training video for more information on using this tool. It is also possible to push in the two buttons by hand as well, if you have good access.
Was this answer helpful?
75% found this helpful
G125-FC10605L0-0300F CAD Model (ZIP file containing STP and IGES)Download
