Product Characteristics

• End Stackable:

  Yes

• Mating Pin Size:

  Ø0.5mm

• Number of Rows:

  2

• Connector Orientation:

  Vertical

• Country of Origin:

  CH

• Side Stackable:

  Yes

• Number of Signal Contacts:

  8

• Operating Temperature:

  -55°C to +125°C

• RoHS Status:

  RoHS Compliant (2015/863/EU) with Exemption 6c

• Current Rating:

  1A per contact

• Soldering Data:

  Max Solder Temperature: 260°C for 10 seconds

• Cuttable:

  No

Materials

• Finish / Plating on Contact Surface:

  Gold

• Housing Material:

  PCT

• Base Material of Contact:

  Beryllium Copper contact clip, Brass shell

• Flammability Rating:

  UL94V-0

• Packaging Style:

  Tube

• Finish / Plating on Termination:

  100% Tin over Nickel

• Housing Colour:

  Black

Dimensions

• Contact Pitch:

  2.54mm (0.1")

• Weight:

  0.758g

• Dimensions:

  10.10 x 10.02 x 11.20

• PC Tail Length:

  3.20mm

• Height of Connector above PCB:

  8.00mm
