M30-1100800

8 Pos. Female SIL Cable Housing

1.25mm (0.049") Pitch PCB Connector - M30 Cable-To-Board

  • Single Row female crimp housing – 8 contact.
  • Bump latches for added retention to mating connector.
  • Use with crimp contacts M30-1050046, M30-1060046 or pre-crimped contacts M30-90 series.
Add to Favorites

Technical Details

Specification

Contact Pitch:

1.25mm (0.049")

Contact Gender:

Female/Socket/Jack

Connector Orientation:

Straight

Connection Type:

Cable (Crimp)

Mating Pin Size:

0.35mm square

Current Rating:

1A per contact

Operating Temperature:

-25°C to +85°C

Polarising Features:

Yes

End Stackable:

No

Side Stackable:

No

Can be cut to another size:

No

Number of Rows:

1

Number of Signal Contacts:

8

Materials

Housing Material:

Polyamide (Nylon) 66

Housing Colour:

Natural

Housing Material UL Rating:

UL94V-0

Packaging Style:

Bulk/Loose

Dimensions

Individual Part Weight:

0.075g

Overall Dimensions (L x W x D) in mm:

11.65 x 3.20 x 4.00

Availability

4,269 in stock

Info Circle

Popular products are manufactured regularly, typically in stock and are not subject to minimum quantity requirements.

Popular product
Distributor Location Quantity (Updated Daily)
Distributor Farnell
Location Europe
Quantity (Updated Daily) 1854
Distributor Newark
Location USA
Quantity (Updated Daily) 1854
Distributor Mouser Electronics Inc
Location Global
Quantity (Updated Daily) 561
