Product Characteristics

• End Stackable:

  No

• Number of Rows:

  2

• Connector Orientation:

  Vertical

• Country of Origin:

  TW

• Side Stackable:

  No

• Number of Power/Coax Contacts:

  4

• Number of Signal Contacts:

  80

• Operating Temperature:

  -55°C to +105°C

• RoHS Status:

  RoHS Compliant (2015/863/EU) with no Exemption required

• Current Rating:

  Signal = 0.5A max per contact; Power = 3A max per contact

• Soldering Data:

  Max Solder Temperature: 260°C for 10 seconds

• Polarised:

  No

• Cuttable:

  No

Materials

• Finish / Plating on Contact Surface:

  Gold

• Housing Material:

  LCP

• Base Material of Contact:

  Copper Alloy

• Flammability Rating:

  UL94V-0

• Packaging Style:

  Tape and Reel

• Finish / Plating on Termination:

  Gold (signal), 100% Tin over Nickel (power)

• Housing Colour:

  Black

Dimensions

• Contact Pitch:

  0.50mm (0.020")

• Weight:

  2.155g

• Dimensions:

  33.70 x 8.90 x 19.55

• PC Tail Length:

  1.35mm

• Height of Connector above PCB:

  18.20mm
