Obsolete 26/07/2018


10+10 Pos. Male DIL Vertical Throughboard Conn. Shielded

2.00mm Pitch High-Reliability Connector - Datamate S-Tek

  • Obsolete – use replacement Metal Backshell M80-9062002 with Male Cable Connector M80-5102042 or M80-5112042for future orders.
  • Double Row, 2.7mm PC Tail connector with 5mm board mount jackscrews – 20 contacts (10+10).
  • Gold finish on contact area, Tin/Lead finish on termination. Slotted nuts provided for assembly to panel mount stud.



Technical Drawing / Datasheet - M80-5T1XXXXB1_obsolete.pdf
