Harwin Shield Can Development Kit wins ECN IMPACT Award

Low-cost convenient alternative to bespoke EMI/RFI shield cans saves time; judged best in category

Harwin, the leading hi-rel connector and SMT board hardware manufacturer, has won the Tools, Kits & Reference Designs category in the prestigious 2015 ECN IMPACT Awards for its Shield Can Development Kit.  The winners were announced at a glittering ceremony held on May 13 at the Mirage in Las Vegas.

Shield Can Kit wins Impact Award 2015

Harwin’s Shield Can Development Kit provides an easy yet elegant method for design engineers to rapidly construct PCB cans, which provide EMI/RFI screening for sensitive electronic circuits during the development phase of a project.  Typically during development and test, engineers have to order bespoke shield cans, without being certain of their eventual requirements.  This incurs costs and creates delays.  Harwin’s Shield Can Kit enables designers to create a shield can of the dimensions required in minutes, at minimal cost, with no special tools or prior experience.  The nickel silver material provides effective and useable shielding with up to 24dB attenuation achieved, depending on frequency and configuration. The kit saves time and money, can shorten the development stage of the design cycle and helps to ensure that the optimal EMC solution is found.

We are delighted to win this Award, particularly against many notable and worthy competitors.  Our Shield Can Kit complements our existing range of EMC solutions and enables both design and production engineers to achieve a timely, cost-effective solution to EMI/RFI shielding.

Paul Gillam | Product Manager

The low cost kit comprises two 80mm x 60mm x 0.3mm thick Nickel Silver sheets that are pre-scribed on a 5mm grid to allowing easy cutting and forming, enabling the user to produce a shield can of the desired dimensions. SMT Shield Can Clips which hold the cans securely in place are also included.

Jessica Engel collecting the ECN Impact award 2015

Image shows Jessica Engel, Harwin Inc, collecting the ECN Impact award
